問題是我是一個PLC工程師，想用寫一個上位機程序和三菱FX3U通訊，PLC的IP地址為192.168.0.250，端口號為5551.要求顯示X0到X7，輸出顯示Y0到Y7，還有M0到M9切換按鈕，輸出格式為直接打開的exe文件
以下是使用C#開發的三菱FX3U上位機通信程序實現方案，包含可直接運行的EXE文件生成方法：
一、開發環境配置
‌開發工具‌：
Visual Studio 2022 (社區版)
.NET Framework 4.8
通信參數‌
NuGet包：Mx.Component.Melsec（三菱協議庫）
var config = new MelsecConfiguration {
    ProtocolType = ProtocolType.TCP,
    Host = "192.168.0.250",
    Port = 5551,
    CpuType = CpuType.FX3U,
    ConnectTimeout = 3000
};
二、界面設計（Windows Forms）
<!-- MainForm.Designer.cs -->
this.Controls.AddRange(new Control[] {
    // X0-X7狀態指示燈
    new StatusLight { Name="x0", Location=new Point(20,20) },
    // ...重復創建x1-x7

    // Y0-Y7狀態顯示
    new StatusLight { Name="y0", Location=new Point(120,20) },
    // ...重復創建y1-y7

    // M0-M9切換按鈕
    new ToggleButton { Name="m0", Text="M0", Location=new Point(220,20) },
    // ...創建m1-m9

    // 狀態欄
    new StatusStrip {
        Items = {
            new ToolStripStatusLabel { Name="lblStatus" }
        }
    }
});
三、核心通信代碼
public partial class MainForm : Form {
    private MelsecFxPLC plc;

    // 初始化PLC連接
    private void ConnectPLC() {
        plc = new MelsecFxPLC(config);
        var result = plc.Connect();

        if (result.IsSuccess) {
            timer1.Interval = 500;  // 500ms輪詢周期
            timer1.Start();
        }
    }

    // 定時讀取狀態
    private void timer1_Tick(object sender, EventArgs e) {
        // 批量讀取X/Y狀態
        var xStatus = plc.ReadBytes("X0", 1);
        var yStatus = plc.ReadBytes("Y0", 1);

        // 更新指示燈
        UpdateLights(xStatus, "x");
        UpdateLights(yStatus, "y");
    }

    // M按鈕點擊事件
    private void mButton_Click(object sender, EventArgs e) {
        var btn = sender as ToggleButton;
        plc.WriteBit($"M{btn.Tag}", btn.Checked);
    }
}
四、可視化組件類
// 狀態指示燈控件
public class StatusLight : PictureBox {
    public StatusLight() {
        Size = new Size(30, 30);
        BackColor = Color.Silver;
    }

    public bool Active {
        set => BackColor = value ? Color.Lime : Color.Red;
    }
}

// 切換按鈕控件
public class ToggleButton : CheckBox {
    public ToggleButton() {
        Appearance = Appearance.Button;
        TextAlign = ContentAlignment.MiddleCenter;
        Size = new Size(50, 30);
    }
}
五、項目打包部署
‌發布設置‌：

項目屬性 → 發布 → 選擇"從CD/USB安裝"
包含.NET Framework 4.8運行庫
生成單文件EXE
‌依賴文件‌
├── MelsecFx.dll
├── Newtonsoft.Json.dll
└── Mx.Component.Core.dll
六、協議處理流程圖
sequenceDiagram
    participant UI as 上位機
    participant PLC as FX3U PLC

    UI->>PLC: TCP Connect(192.168.0.250:5551)
    PLC-->>UI: 連接成功響應

    loop 500ms輪詢
        UI->>PLC: 讀取X0-X7(0x00B0命令)
        PLC-->>UI: X狀態數據
        UI->>PLC: 讀取Y0-Y7(0x00B0命令)
        PLC-->>UI: Y狀態數據
    end

    UI->>PLC: 寫入M位(0x1401命令)
    PLC-->>UI: 寫入確認
七、測試驗證步驟
‌PLC準備‌：
; 測試程序
LD M8000
MOV K85 K1Y0  // Y0-Y7循環顯示
‌上位機操作檢查表‌：

估計它也在等軟件工程師寫完程序并在網上開源吧！

using System;
using System.Collections.Generic;
using System.Drawing;
using System.Net.Sockets;
using System.Text;
using System.Windows.Forms;

namespace MELSEC_FX3U_Comm
{
    public partial class MainForm : Form
    {
        private TcpClient plcClient;
        private NetworkStream stream;
        private Timer refreshTimer;
        private byte station = 0x00;

        // PLC寄存器狀態存儲
        private bool[] xStatus = new bool[8];
        private bool[] yStatus = new bool[8];
        private bool[] mStatus = new bool[10];

        public MainForm()
        {
            InitializeComponent();
            InitializePLCConnection();
            SetupUI();
            StartRefreshTimer();
        }

        private void InitializePLCConnection()
        {
            try
            {
                plcClient = new TcpClient();
                plcClient.Connect(IPAddress.Parse("192.168.0.250"), 5551);
                stream = plcClient.GetStream();
                StatusLabel.Text = "已連接到PLC";
            }
            catch (Exception ex)
            {
                StatusLabel.Text = $"連接失敗: {ex.Message}";
            }
        }

        private void SetupUI()
        {
            // 初始化輸入顯示區域
            for (int i = 0; i < 8; i++)
            {
                var cb = new CheckBox
                {
                    Text = $"X{i}",
                    Location = new Point(20 + (i % 4) * 80, 20 + (i / 4) * 30),
                    AutoSize = true
                };
                xCheckBoxes.Add(cb);
                this.Controls.Add(cb);
            }

            // 初始化輸出顯示區域
            for (int i = 0; i < 8; i++)
            {
                var cb = new CheckBox
                {
                    Text = $"Y{i}",
                    Location = new Point(200 + (i % 4) * 80, 20 + (i / 4) * 30),
                    AutoSize = true
                };
                yCheckBoxes.Add(cb);
                this.Controls.Add(cb);
            }

            // 初始化M寄存器按鈕
            for (int i = 0; i < 10; i++)
            {
                var btn = new Button
                {
                    Text = $"M{i}",
                    Location = new Point(380 + (i % 5) * 80, 20 + (i / 5) * 30),
                    Width = 70
                };
                btn.Click += (s, e) => ToggleMRegister(i);
                mButtons.Add(btn);
                this.Controls.Add(btn);
            }
        }

        private void StartRefreshTimer()
        {
            refreshTimer = new Timer { Interval = 500 };
            refreshTimer.Tick += async (s, e) => await ReadPLCData();
            refreshTimer.Start();
        }

        private async Task ReadPLCData()
        {
            try
            {
                // 讀取X寄存器
                byte[] xData = ReadRegisters(0x0000, 8);
                for (int i = 0; i < 8; i++)
                    xStatus = (xData[i / 8] & (1 << (7 - (i % 8)))) != 0;

                // 讀取Y寄存器
                byte[] yData = ReadRegisters(0x0010, 8);
                for (int i = 0; i < 8; i++)
                    yStatus = (yData[i / 8] & (1 << (7 - (i % 8)))) != 0;

                UpdateUI();
            }
            catch (Exception ex)
            {
                StatusLabel.Text = $"讀取錯誤: {ex.Message}";
            }
        }

        private byte[] ReadRegisters(ushort start, ushort length)
        {
            // 構建讀取請求報文
            List<byte> query = new List<byte>
            {
                0x80, 0x00, 0x00, 0x00,           // 起始符
                0x00, 0x02,                         // 控制代碼
                (byte)(station), 0x00, 0x00,      // 站號、保留
                (byte)(start >> 8), (byte)start,  // 起始地址
                (byte)(length >> 8), (byte)length,// 寄存器數量
                0x00, 0x00                          // 結束符
            };

            SendCommand(query.ToArray());
            return ReadResponse();
        }

        private void ToggleMRegister(int index)
        {
            mStatus[index] = !mStatus[index];
            WriteRegister(0x2000 + index, mStatus[index] ? 1 : 0);
            mButtons[index].BackColor = mStatus[index] ? Color.LightGreen : SystemColors.Control;
        }

        private void WriteRegister(ushort address, ushort value)
        {
            // 構建寫請求報文
            List<byte> query = new List<byte>
            {
                0x80, 0x00, 0x00, 0x00,           // 起始符
                0x00, 0x12,                         // 控制代碼
                (byte)(station), 0x00, 0x00,      // 站號、保留
                (byte)(address >> 8), (byte)address,// 地址
                (byte)(value >> 8), (byte)value,  // 值
                0x00, 0x00                          // 結束符
            };

            SendCommand(query.ToArray());
        }

        private void SendCommand(byte[] command)
        {
            stream.Write(command, 0, command.Length);
        }

        private byte[] ReadResponse()
        {
            byte[] buffer = new byte[1024];
            int bytesRead = stream.Read(buffer, 0, buffer.Length);
            Array.Resize(ref buffer, bytesRead);
            return buffer;
        }

        private void UpdateUI()
        {
            // 更新X寄存器顯示
            for (int i = 0; i < 8; i++)
                xCheckBoxes.Checked = xStatus;

            // 更新Y寄存器顯示
            for (int i = 0; i < 8; i++)
                yCheckBoxes.Checked = yStatus;

            // 更新M寄存器顯示
            for (int i = 0; i < 10; i++)
                mButtons.BackColor = mStatus ? Color.LightGreen : SystemColors.Control;
        }

        protected override void OnFormClosing(FormClosingEventArgs e)
        {
            base.OnFormClosing(e);
            plcClient?.Close();
        }

        [STAThread]
        static void Main()
        {
            Application.EnableVisualStyles();
            Application.SetCompatibleTextRenderingDefault(false);
            Application.Run(new MainForm());
        }
    }
}

你的問題提得不行

你是一個PLC工程師，這個是你自己的內心臺詞。你應該以工程師的角度，提出專業的需求，它幫你做到。而不是輸入：我是PLC工程師。
比如，你可以輸入人機界面的品牌 型號，你需要哪些軟按鍵功能，讓AI給你做觸摸屏程序。
再輸入PLC信息，使用的通訊協議等等，讓AI給你寫通訊程序。

引用

引用第4樓cstw18于2025-04-24 08:18發表的  :
你是一個PLC工程師，這個是你自己的內心臺詞。你應該以工程師的角度，提出專業的需求，它幫你做到。而不是輸入：我是PLC工程師。
比如，你可以輸入人機界面的品牌 型號，你需要哪些軟按鍵功能，讓AI給你做觸摸屏程序。
再輸入PLC信息，使用的通訊協議等等，讓AI給你寫通訊程序。

牛逼

感謝分享

感謝分享

感謝分享，謝謝。
